ADVENTURE ON AND OFF-ROAD RIDING
Is it a gravel bike? Is it a mountain bike? Well, it's both - the Marin DSX FS breaks the gravel bike mold even further by adding a 60mm SR/Suntour front suspension fork for hard-charging, off-road adventures. There’s also a 12-speed 1X Shimano SLX drivetrain, Vee Tire Co tires, Shimano hydraulic brakes and plenty of reliable Marin components.
The Marin DSX is everything you want from a modern, flat-bar gravel bike.
Zippy aluminum frames, compliant forks, heaps of tire clearance, low standover, dropper post compatibility and a whole load of options for bags and fenders. Taking inspiration from the Gestalt X drop bar line, we made the DSX to feel like an MTB but still cut it on all of those adventures that would normally demand curly bars.
Perfect for racking up road miles, daily grinds to work, multi-day epics and flowy singletrack, the DSX is the perfect modern gravel bike for riders that prefer their bars flat.
Specifications
-
Frame
Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
-
Fork
SR/Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts
-
Rims
Marin Aluminum Double Wall, 21mm Inner, Disc Specific, Tubeless Compatible
-
Hub, Rear
Forged Aluminum, 142x12mm, Disc Specific, 32H
-
Hub, Front
Forged Aluminum, 100x12mm, Disc, 32H
-
Spoke, Nipples
14g Black Stainless Steel
-
Tires
Vee Tire Co., QuikStyk, 700x45,Folding Bead, Tubeless Compatible
-
Derailleur, Rear
| Shimano Deore, RD6100, 12-Speed |
|
-
-
Shift Lever
Shimano Deore, SLM6100, 12-Speed
-
Crankset
Forged Aluminum, 42T Steel Narrow Wide Chainring
-
Bottom Bracket
Sealed Outboard Bearing
-
-
Cassette
SunRace, 12-Speed, 11-51T
-
Brake, Front
| Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor |
-
Brake, Rear
| Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor |
-
Brake Levers
Tektro Hydraulic
-
Handlebar
Marin Mini Riser
-
Stem
Marin 3D Forged Alloy
-
-
Headset
FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
-
-
-
-
Extras
Bolt-On Thru-Axles F and R
Specifications, pricing, and availability are subject to change without notice.
